“Looking for the spec on a 2008 Honda CRF230L? You have landed on the right page. Please note there are a few minor difference between the two production years sold in the US. Take a look below to find all of the specs for the 2008 CRF230L”
2008 Honda CRF230l Specs:
| Model: | 2008 CRF230L |
| Engine Type: | 223cc air-cooled single-cylinder four-stroke |
| Bore and Stroke: | 65.5mm x 66.2mm |
| Compression Ratio: | 9.0:1 |
| Valve Train: | SOHC; two-valve |
| Induction: | Carburetor 30mm CV |
| Ignition: | CD |
| Transmission: | Six-speed |
| Final Drive: | Chain: #520 O-ring-sealed chain Front Sprocket: 13 Tooth Rear Sprocket: 39 Tooth |
| Suspension: | Front: 37mm leading-axle Showa fork; 9 inches of travel Rear: Pro-Link Showa shock w/ preload adjustability; 6.3 of inches travel |
| Brakes: | Front: Single 240mm disc Rear: 220mm disc |
| Tires: | Front: 2.75-21 Rear: 120/80-18 |
| Wheels: | Front: 1.65×21 Rear: 2.15×18 |
| Wheelbase: | 52.75 inches |
| Rake: | 26.83° |
| Trail: | 103mm ( 4.0 inches ) |
| Seat Height: | 31.9 inches |
| Ground Clearance: | 9.5 inches |
| Fuel Capacity: | 2.3 gallons, including 0.7 gallon reserve |
| Color: | Red |
| Curb Weight Wet: | 267 pounds |
